LED Strip Switching Power Supply AC110V-240V to DC12V 60W 5A 160*40*32mm S-60-12

Availability: In stock

Regular Price: SGD56.00

Special Price SGD31.00

You Save: SGD25.00 (45%)

Quick Overview

Feature:

1. International AC input range
2. High efficiency, low working temperature
3. Short circuit,overload,over-current protection
4. 100% fully load burn-in test
5. Built-in EMI filter, low ripple noise
6. Low cost, high reliability
7. CE and FCC approval

Specification:

1. LED switching power supply using pulse width modulation (PWM) switching technology designed to ensure power supply stability and high efficiency.
2. Product interference, through the EMC testing, ripple ≤ 50MV.
3. Efficiency above 80%, temperature ≤ 25 °C.
4. LED switching power supply with overvoltage protection, short circuit protection, overload protection.
5. Constant current output to ensure the stability of the power, so that LED lighting effects better and live longer.
6. Products have the anti-interference ensures long-life LED strips, reducing the LED lighting decline.

ModelS-60-12
AC input voltage range220VAC
Input current0.3A/230V
AC impulse currentCold-start current 4.5A/230V
DC output voltage12V
DC output power60W
Rated output current5A
Output voltage error±1%
Efficiency85%
Wave and noise150mVp-p
Inlet stability±0.5%
Load stability±0.5%
Leakage current<0.5mA/230VAC
Overload protection105% - 150% rated power, automatically recovery
Vibration10500Hz,2G 10min./1cycle,Period for 60min,Each axes
Cooling methodFan assisted cooling
Working temperature and humidity- 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost)
Store temperature and humidity- 30 ° ~ 85 ° c / 10% ~ 95% RH (no frost)
Safety standardsCE(EMC+LVD) , FCC.
Dimension160x40x32mm
Weight0.186kg

Package includes:

1 x Power supply
